Containerized Mobile Burner CA100

This layout is little medical waste incineration devices. Building and construction is dual/double

Model

CA100

combustion chamber with 02 units oil burner, batch load incineration equipment. Animal feed
chamber is 560Liters (Model CA100). Primary & Secondary combustion chambers and smoke
filter chamber with firebrick and  refractory concrete chamber. Batch load on the bottom of
chamber. Incinerator panel control suit for local operation.

Waste Remedy

Medical Waste Incineration Remedy

Feed Capacity

Typical 100-200 kgs per feed

Burning Price

Average 100-120 kgs per hr

Burning Time per Feed

Average 1-2 hr

Control Mode

PLC( Programmable Logic Controller Incinerator)

Voltage

220V

Power

1.0 Kw

Gas

Diesel oil

Burner

Italy Heater

Feed Setting

Manual

Temperature Screen

Digital Screen

Fuel intake (Oil)

Average 20.4 Kgs/Hour

Inner Dimensions

100x80x70cm (Key Combustion Chamber)

External Capacities

230 x 130 x 155cm (main body)

Waste burning chamber

560Liters

Blog Post Combustion Chamber

280Liters

Oil Container Ability

200 Liters

Door Opening

70 x 50cm

Smokeshaft

5.0 M

Gross Weight

4500kgs

Chamber Material

Firebrick, Refractory Concrete

Max. Heat Worth

166,000 Kcal/Hr.

Operation Technical Specifications

Solid Chamber temperature

8000C -10000 C

Concentration camp temperature level

10000C -12000 C

Chamber Anti-Rate

17500C

Residency time

2.0 Sec.

Burning performance

> 98 percent

Waste Lower Calorific Power

3000Kcal

Pre-assembled, containerized type,do not included chimney installation.Burning rate: 100 – 120kg / hour.
Minimum operating temperature 800-1000 degree.Maximum operating temperature:1000-1200 degree.
Secondary Burning capacity.Density insulation.Refractory casting.Heavy duty refracting lining to
withstand 1750 degree.Fuel type: fuel oil (diesel).

100Kg/Hour Burning rate with Secondary burning Capacity
