Medical Waste Incinerator Capacity Standard 100kgs per hour

Temperature Level Show & & PLC Control Instance

Main Burning Chamber

Incinerator Text

***Primary Combustion Chamber

Italy Oil/Gas Heater

***Chimney:10.0Meters

*** Second Combustion Chamber *** Smoke Filter Chamber

***Italy oil/gas burner: 02 units
***Oil Tank (if oil fuel): 200Liters

*** Burner PLC Control Instance


Items/Model

TS100( PLC)

Concept

Waste Incineration Treatment

Burn Price

Standard 100 kg/hour

Feed Ability

Average 200kg/feeding

Control Mode

PLC( Programmable Reasoning Controller Incinerator)

Combustion Chamber

1200L

Inner Measurements

120x100x100cm

Added Chamber

600L

Smoke Filter Chamber

Yes( Dry Scrubber)

Feed Mode

Manual

Voltage

220V

Power

0.7 Kw

Oil Utilization (kg/hour)

14—- 28

Gas Utilization (m3/hour)

10—- 32.2

Temperature Display

Digital Show

Temperature Protection

Yes

Oil Storage Tank

200L

Feed Door

80x60cm

Smokeshaft

10Meter

Smokeshaft Type

Stainless-steel

1st.

800 ℃—- -1000 ℃

second. Chamber Temperature Level

1000 ℃ -1200 ℃

Residency Time

2.0 Sec.

Gross Weight

6000kg

Exterior Measurements

HICLOVER – Medical Environmental

260x150x180cm



Waste Incinerators
Medical Waste Incinerator
Pet Animal Cremation
Solid Waste Incinerator
